Cast Chains, Type C55, C60, C77, C188, C102B, C110, C132, CC600, 445, 477, 488, CC1300, MC33, H78A, H78B
Cast combination chains
|
GL |
Pitch(mm) |
Dimension(mm) |
Ultimate Strength(KN) |
Weight(Kg/m) |
|||
|
Chdn No. |
Pitch |
B |
C |
T |
D |
Ultimate Strength |
Weight |
|
C55 |
41.4 |
32.0 |
19.0 |
4.8 |
9.5 |
40.0 |
3.2 |
|
C60 |
58.6 |
42.9 |
25.4 |
7 |
12.7 |
71.0 |
4.47 |
|
C77 |
58.6 |
32.0 |
22.0 |
4.8 |
11.1 |
49.0 |
3.4 |
|
Cl 88 |
66.3 |
39.6 |
29.0 |
5.8 |
12.7 |
62.0 |
5.3 |
|
C102B |
101.6 |
73.0 |
38.1 |
9.5 |
20.0 |
107.0 |
9.4 |
|
eno |
152.4 |
72.0 |
38.1 |
9.5 |
16.0 |
107.0 |
9.3 |
|
Cl 32 |
153.6 |
111.0 |
50.8 |
12.7 |
25.4 |
272.0 |
21.6 |
Cast chains for conveyors
|
GL |
Pitch(mm) |
Dimens ion (mm) |
Ultimate Strength(KN) |
Weight(Kg/m) |
||||
|
Chdn No. |
Pitch |
A |
B |
C |
T |
D |
Ultimate Strength |
Weight |
|
CC600 |
63.5 |
23.5 |
43.0 |
29.0 |
8.0 |
11.0 |
74.0 |
5.4 |
|
CC1300 |
82.5 |
30.2 |
50.8 |
38.1 |
9.5 |
14.2 |
109.0 |
4.2 |
|
GL |
Pitch(mm) |
Dimension(mm) |
Ultimate Strength(KN) |
Weight(Kg/m) |
||||
|
Chdn No. |
Pitch |
A |
B |
C |
T |
D |
Ultimate Strength |
Weight |
|
MC33 |
63.5 |
18.0 |
38.1 |
32.0 |
8.6 |
12.7 |
49.0 |
5.1 |
Cast pintle chains-400
|
GL |
Pitch(mm) |
Dimension(mm) |
Ultimate Strength(KN) |
Weight(Kg/m) |
|||
|
Chdn No. |
Pitch |
A |
B |
C |
D |
Ultimate Strength |
Weight |
|
442 |
34.93 |
26.92 |
50.80 |
19.05 |
7.94 |
27.0 |
2.23 |
|
445 |
41.40 |
26.92 |
50.80 |
19.05 |
7.94 |
27.0 |
2.38 |
|
452 |
38.25 |
27.69 |
56.36 |
21.43 |
9.26 |
31.0 |
3.27 |
|
455 |
41.40 |
28.45 |
57.94 |
21.43 |
9.26 |
31.0 |
3.13 |
|
462 |
41.50 |
36.58 |
65.09 |
23.81 |
11.11 |
39.0 |
4.02 |
|
477 |
58.62 |
31.75 |
64.29 |
25.40 |
11.11 |
43.0 |
3.27 |
|
488 |
66.27 |
41.00 |
75.00 |
25.40 |
11.11 |
49.0 |
4.61 |
|
GL |
Pitch(mm) |
Dimension(mm) |
Ultimate Strength(KN) |
Weigh(Kg/m) |
|||
|
Chdn No. |
Pitch |
A |
B |
C |
D |
Ultimate Strength |
Weight |
|
4103 |
78.11 |
47.60 |
87.00 |
38.00 |
19.05 |
1240 |
9.23 |
|
4124 |
103.20 |
58.00 |
108.00 |
44.50 |
20.64 |
166.0 |
13.69 |
Cast pintle chains-500&700
|
GL |
Pitch(mm) |
Dimension(mm) |
Ultimate Strength(KN) |
Weight(Kg/M) |
|||
|
Chdn No. |
Pitch |
A |
B |
C |
D |
Ultimate Strength |
Weight |
|
503 |
76.70 |
50.80 |
107.20 |
33.30 |
14.00 |
90.0 |
9.23 |
|
504 |
103.10 |
73.20 |
146.00 |
42.90 |
16.00 |
122.0 |
12.65 |
|
GL |
Pitch(mm) |
Dimension(nrn) |
Ultimate Strength(KN) |
Weight(Kg/m) |
|||
|
Chdn No. |
Pitch |
A |
B |
C |
D |
Ultimate Strength |
Weight |
|
710 |
119.63 |
78.60 |
142.88 |
37.00 |
17.46 |
122.0 |
9.38 |
|
720 |
152.40 |
45.97 |
90.09 |
38.10 |
17.46 |
122.0 |
6.25 |
|
720S |
152.40 |
47.70 |
92.40 |
39.60 |
19.05 |
167.0 |
7.74 |
|
730 |
41.50 |
50.80 |
96.00 |
44.45 |
19.05 |
187.0 |
8.93 |
Cast chains are manufactured using cast links and heat treated steel pins. They are designed with slightly larger clearances that allow the material to easily work its way out of the chain joint. Cast chains are used in a variety of applications such as sewage treatment, water filtration, fertilizer handling, sugar processing and waste wood conveying. They are readily available with attachments.
