Platewheels per Asian Standard
K25A
SPROCKETS | mm |
Tooth width (T) | 2.8 |
CHAIN | mm |
Pitch (P) | 6.35 |
Internal width | 3.18 |
Roller Φ (Dr) | 3.30 |
Type |
Teeth |
Do |
Dp |
Bored |
Wt kg |
Material |
|
Stock |
Min |
||||||
K25A |
10 |
23 |
20.55 |
9 |
11 |
0.02 |
C45 Solid |
12 |
28 |
24.53 |
9 |
11 |
0.03 |
||
13 |
30 |
26.53 |
9 |
11 |
0.04 |
||
14 |
32 |
28.54 |
9 |
11 |
0.04 |
||
15 |
34 |
30.54 |
9 |
11 |
0.05 |
||
16 |
36 |
32.55 |
9 |
11 |
0.05 |
||
17 |
38 |
34.56 |
9 |
11 |
0.07 |
||
18 |
40 |
36.57 |
9 |
11 |
0.07 |
||
20 |
44 |
40.59 |
9 |
11 |
0.09 |
||
24 |
52 |
48.65 |
9 |
11 |
0.14 |
||
25 |
54 |
50.66 |
9 |
11 |
0.16 |
||
27 |
58 |
54.70 |
9 |
11 |
0.17 |
||
28 |
60 |
56.71 |
9 |
11 |
018 |
||
29 |
62 |
58.73 |
9 |
11 |
0.20 |
||
30 |
64 |
60.75 |
10 |
12 |
0.23 |
||
32 |
68 |
64.78 |
10 |
12 |
0.27 |
||
33 |
70 |
66.80 |
10 |
12 |
0.28 |
||
35 |
74 |
70.84 |
10 |
12 |
0.30 |
||
36 |
76 |
72.86 |
10 |
12 |
032 |
||
37 |
78 |
74.88 |
10 |
12 |
0.37 |
||
38 |
80 |
76.90 |
10 |
12 |
0.41 |
||
40 |
84 |
80.93 |
11 |
13 |
0.43 |
||
42 |
89 |
84.97 |
11 |
13 |
0.47 |
||
45 |
95 |
91.03 |
11 |
13 |
0,50 |
||
50 |
105 |
101.13 |
11 |
13 |
0.59 |
||
55 |
115 |
111.23 |
11 |
13 |
0.70 |
||
60 |
125 |
121.33 |
11 |
13 |
0.87 |
||
70 |
145 |
141.54 |
11 |
13 |
1.81 |
||
75 |
155 |
151.64 |
12 |
14 |
1.37 |
||
80 |
165 |
161.74 |
12 |
14 |
1.62 |
K25A
SPROCKETS | mm |
Tooth width (T) | 4.3 |
CHAIN | mm |
Pitch (P) | 9.25 |
Internal width | 4.78 |
Roller Φ (Dr) | 5.08 |
Type |
Teeth |
Do |
Dp |
Bored |
wt kg |
Material |
|
Stock |
Min |
||||||
K35A |
10 |
34 |
30.82 |
9 |
11 |
0.02 |
C45 Solid |
11 |
38 |
33.81 |
9 |
11 |
0.03 |
||
12 |
41 |
36.80 |
9 |
11 |
0.03 |
||
13 |
44 |
39.80 |
9 |
11 |
0.04 |
||
14 |
47 |
42.81 |
9 |
11 |
0.04 |
||
15 |
51 |
45.81 |
9 |
11 |
0.05 |
||
16 |
54 |
48.82 |
9 |
11 |
0.05 |
||
17 |
57 |
51.84 |
11 |
13 |
0.07 |
||
18 |
60 |
54.85 |
11 |
13 |
0.07 |
||
19 |
63 |
57.87 |
11 |
13 |
0.09 |
||
20 |
66 |
60.89 |
11 |
13 |
0.09 |
||
21 |
69 |
63.91 |
11 |
13 |
0.11 |
||
22 |
72 |
66.93 |
11 |
13 |
0.11 |
||
23 |
75 |
69,95 |
11 |
13 |
0.11 |
||
24 |
78 |
72.97 |
11 |
13 |
0.14 |
||
25 |
81 |
76.00 |
11 |
13 |
0.16 |
||
26 |
84 |
79.02 |
11 |
13 |
0.16 |
||
27 |
87 |
82,05 |
11 |
13 |
0.17 |
||
28 |
90 |
85.07 |
11 |
13 |
0.18 |
||
30 |
96 |
9142 |
11 |
13 |
0.23 |
||
32 |
102 |
97.18 |
11 |
13 |
0.27 |
||
33 |
105 |
100.20 |
11 |
13 |
0.28 |
||
34 |
109 |
103.23 |
11 |
13 |
0.29 |
||
35 |
112 |
106.26 |
11 |
13 |
0.30 |
||
36 |
115 |
109.29 |
12 |
14 |
0.32 |
||
38 |
121 |
115.34 |
12 |
14 |
0.37 |
||
40 |
127 |
121.40 |
12 |
14 |
0.40 |
||
42 |
133 |
127.46 |
16 |
18 |
0.43 |
||
45 |
142 |
136.55 |
16 |
18 |
0.49 |
||
46 |
145 |
139.58 |
16 |
18 |
0.51 |
||
4S |
151 |
145.64 |
16 |
18 |
0.55 |
||
50 |
157 |
151.70 |
16 |
18 |
0.60 |
||
54 |
169 |
163.81 |
16 |
18 |
0.70 |
||
55 |
172 |
166.85 |
16 |
18 |
0.71 |
||
60 |
187 |
182.00 |
16 |
18 |
0.80 |
||
65 |
203 |
197.15 |
16 |
18 |
1.02 |
||
70 |
218 |
212,30 |
16 |
18 |
1.18 |
||
80 |
24B |
242.60 |
16 |
18 |
1.50 |
K410A
SPROCKETS | mm |
Tooth width (T) | 2.8 |
CHAIN | mm |
Pitch (P) | 12.70 |
Internal width | 3.4 |
Roller Φ (Dr) | 7.75 |
Type |
Teeth |
Do |
Dp |
Bored |
Wt kg |
Material |
|
Stock |
Min |
||||||
K410A |
8 |
38 |
33.19 |
10 |
12 |
0.01 |
C45 Solid |
9 |
42 |
37.13 |
10 |
12 |
0.02 |
||
10 |
46 |
41.10 |
11 |
13 |
0.05 |
||
11 |
51 |
45.08 |
12 |
14 |
0.09 |
||
12 |
55 |
49.07 |
12 |
14 |
0.10 |
||
13 |
59 |
53.07 |
15 |
17 |
0,12 |
||
14 |
63 |
57.07 |
15 |
17 |
0.14 |
||
IS |
67 |
61.08 |
15 |
17 |
0.16 |
||
16 |
71 |
65.10 |
15 |
17 |
0.18 |
||
17 |
76 |
69.12 |
15 |
17 |
0.20 |
||
18 |
80 |
73.14 |
15 |
17 |
0.23 |
||
19 |
84 |
77.16 |
15 |
17 |
0.26 |
||
20 |
88 |
81.18 |
16 |
18 |
0.29 |
||
21 |
92 |
85.21 |
16 |
18 |
0.30 |
||
22 |
96 |
89.24 |
16 |
18 |
0.35 |
||
23 |
100 |
93.27 |
16 |
18 |
0.38 |
||
24 |
104 |
9730 |
16 |
18 |
0.40 |
||
25 |
108 |
101.33 |
16 |
18 |
0.45 |
||
26 |
112 |
105.36 |
16 |
18 |
0.49 |
||
27 |
116 |
109.40 |
16 |
18 |
0.50 |
||
28 |
120 |
113.43 |
16 |
18 |
0.56 |
||
29 |
124 |
117.46 |
16 |
18 |
0.60 |
||
30 |
128 |
12L50 |
16 |
18 |
0.63 |
||
31 |
133 |
125.53 |
16 |
18 |
0.65 |
||
32 |
137 |
129.57 |
16 |
18 |
0.70 |
||
33 |
141 |
133.61 |
16 |
18 |
0.75 |
||
34 |
145 |
137.64 |
16 |
18 |
0.80 |
||
35 |
149 |
141.68 |
16 |
18 |
0.85 |
||
36 |
153 |
145.72 |
18 |
20 |
0.90 |
||
37 |
157 |
149.75 |
18 |
20 |
0.99 |
||
38 |
161 |
153.79 |
18 |
20 |
1.00 |
||
39 |
165 |
157.83 |
18 |
20 |
1.18 |
||
40 |
169 |
161.87 |
18 |
20 |
1.20 |
||
41 |
173 |
165.91 |
18 |
20 |
1.20 |
||
42 |
177 |
169.94 |
18 |
20 |
1.25 |
||
44 |
185 |
178.02 |
18 |
20 |
135 |
||
45 |
189 |
182.06 |
18 |
20 |
1.40 |
||
46 |
193 |
186.10 |
18 |
20 |
1.49 |
||
47 |
197 |
190.14 |
18 |
20 |
1.58 |
||
48 |
201 |
194.18 |
18 |
20 |
1.63 |
||
49 |
205 |
198.22 |
18 |
20 |
1.73 |
||
50 |
209 |
202.26 |
18 |
20 |
1.80 |
||
52 |
218 |
210.34 |
18 |
20 |
1.93 |
||
54 |
226 |
Z18-42 |
18 |
20 |
2.00 |
||
60 |
250 |
242.66 |
18 |
20 |
2.60 |
K40A
SPROCKETS | mm |
Tooth width (T) | 7.2 |
CHAIN | mm |
Pitch (P) | 12.7 |
Internal width | 7.95 |
Roller Φ (Dr) | 7.95 |
Type |
Teeth |
Do |
Dp |
Bored Stock |
Min |
Wt kg |
Material |
K4OA |
10 |
46 |
41.10 |
9.5 |
115 |
0.05 |
C45 Solid |
11 |
51 |
45.08 |
10.5 |
12.5 |
0.09 |
||
12 |
55 |
49.07 |
11.5 |
13.5 |
0.10 |
||
13 |
59 |
53.07 |
13.5 |
15-5 |
0.12 |
||
14 |
63 |
57.07 |
13.5 |
15.5 |
0.14 |
||
15 |
67 |
61.08 |
13.5 |
15.5 |
0J6 |
||
16 |
71 |
65.10 |
13.5 |
15.5 |
0.18 |
||
17 |
76 |
69.12 |
13.5 |
15,5 |
0.20 |
||
18 |
80 |
73.14 |
13-5 |
15,5 |
0.23 |
||
19 |
84 |
77.16 |
13.5 |
15.5 |
0.26 |
||
20 |
88 |
81.18 |
14 |
16 |
0.29 |
||
21 |
92 |
85.21 |
14 |
16 |
0.30 |
||
22 |
96 |
89.24 |
14 |
16 |
0.35 |
||
23 |
100 |
93.27 |
14 |
16 |
0.38 |
||
24 |
104 |
97.30 |
14 |
16 |
0.40 |
||
25 |
108 |
101.33 |
14 |
16 |
0.45 |
||
26 |
112 |
105.36 |
14 |
16 |
0.49 |
||
27 |
116 |
109.40 |
14 |
16 |
0.50 |
||
28 |
120 |
113.43 |
14 |
16 |
0.56 |
||
29 |
124 |
117.46 |
14 |
16 |
0.60 |
||
30 |
128 |
121.50 |
14 |
16 |
0.63 |
||
31 |
133 |
125.53 |
14 |
16 |
0.65 |
||
32 |
137 |
129.57 |
14 |
16 |
0.70 |
||
33 |
141 |
133.61 |
14 |
16 |
0.75 |
||
34 |
145 |
137.64 |
14 |
16 |
0-80 |
||
35 |
149 |
141,68 |
14 |
16 |
0.85 |
||
36 |
153 |
145.72 |
16 |
18 |
0.90 |
||
37 |
157 |
149.75 |
16 |
18 |
0.99 |
||
38 |
161 |
153.79 |
16 |
18 |
1.00 |
||
39 |
165 |
157.83 |
16 |
18 |
1.15 |
||
40 |
169 |
161.87 |
16 |
18 |
1.20 |
||
41 |
173 |
165.91 |
16 |
18 |
1.20 |
||
42 |
177 |
169.95 |
16 |
18 |
1.25 |
||
43 |
181 |
173.98 |
16 |
18 |
1.30 |
||
44 |
185 |
178.02 |
16 |
18 |
1.35 |
||
45 |
189 |
182.06 |
16 |
18 |
1.40 |
||
46 |
193 |
186.10 |
16 |
18 |
1.49 |
||
47 |
197 |
190.14 |
16 |
18 |
1.58 |
||
48 |
201 |
194.18 |
16 |
18 |
1-63 |
||
49 |
205 |
198.22 |
16 |
18 |
1.73 |
||
50 |
209 |
202.26 |
16 |
18 |
1.80 |
||
51 |
214 |
206.30 |
16 |
18 |
1.88 |
||
52 |
218 |
210.34 |
16 |
18 |
1.93 |
||
53 |
222 |
214.38 |
16 |
18 |
1.98 |
||
54 |
226 |
218.42 |
16 |
18 |
2.00 |
||
S5 |
230 |
222.46 |
16 |
18 |
2.18 |
||
56 |
234 |
226.50 |
16 |
18 |
2.26 |
||
58 |
242 |
234.58 |
16 |
18 |
2.43 |
||
59 |
246 |
238.62 |
16 |
18 |
2.51 |
||
60 |
250 |
242,66 |
16 |
18 |
2.60 |
||
62 |
258 |
250.74 |
16 |
18 |
2.77 |
||
64 |
266 |
258.83 |
16 |
18 |
2.90 |
||
65 |
270 |
262.87 |
16 |
18 |
3.00 |
||
68 |
282 |
274.99 |
16 |
18 |
3.35 |
||
70 |
290 |
283.07 |
16 |
18 |
3.50 |
||
72 |
299 |
291.16 |
20 |
22 |
370 |
||
75 |
311 |
303,28 |
20 |
22 |
4.00 |
||
80 |
331 |
323.49 |
20 |
22 |
4.60 |
||
85 |
351 |
343.69 |
20 |
22 |
5.20 |
||
90 |
371 |
363.90 |
20 |
22 |
5.80 |
Plate wheel:
The plate wheel helps to determine the performance and service life of the chain
Plate wheels help determine the performance and service life of the chain, so GL provides appropriate corresponding plate wheels from its extensive inventory of all chains. This ensures proper alignment between the chain and the plate wheels and prevents fit differences that can affect the overall life of the chain drive. GL also manufactures the sprockets and plate wheels from solid materials or welded material exactly as the customer requires. GL offers a variety of tooth shapes and material options with or without hardened teeth. Designs include simplex, duplex, triplex and cast iron. European standard / AMERICA standard / Asian standard are avilable.
